UIMPL Metrology Lab is well equipped as per ISO/IEC17025-2005 to cater to the stringent reauirements of the quality management System laid down by ISO 9001,TS 16949 and AS 9100 for calibration.we deliver comprehensive Calibration services for a range of gauges and instruments in linear dimensional measurements.we assure total satisfaction through accurate and reliable calibration services,traceble to national and international standards


We have a team of highly skilled personal having relevant expertise in undertaking calibration. Our Laboratory's sophisticated Environmental control System Continously monitors and maintains strict environmental conditions, which include floor vibration isolation,Air particle filtrations,and the latest temperature control technology to maintain 20+/0.5degc.

Initially the objective was to calibration of mechanical instruments and gauges to meet ISO 9001 requirement with minimum facilities. Subsequently business has expanded in multi-folds.


Initially the objective was to cater calibration of mechanical instruments and gauges to meet ISO 9001 requirement with minimum facility. subsequently business has explained in multi folds. Accordingly additional calibration facilities were added to meet the increase in demand. Unique meteorology lab has the distinction of getting ISO 9001 & AS 9100C Certification,in addition to NABL 17025 accreditation for calibration



Lab



Laser Calibration

RENISHAW XL-80 Laser System

With interferometer calibration of Vertical Machining Centre, Horizontal Machining Centre, CNC Lathe, Jig Boring Machine & CNC Turning Machine with DRO & CNC Controller, etc. Accuracy + or -0.5 ppm Resolution : 1nm Range : 80 Mtr.


RENISHAW XL-80 Laser System

  • Accuracy + or -0.5 ppm
  • Resolution : 1nm
  • Range : 80 Mtr.



RENISHAW QC 10 Ball Bar System

Qc 10 BALL BAR For quick diagnose the machine performance to :

  • Achieve manufacturing tolerances
  • Grade & compare machines
  • Test & monitor machine condition
  • Predict maintenance requirements
  • Check new machines at commissioning


Design features

  • Underground building with Double wall and air gap on all sides
  • Expanded polystyrene insulation
  • Vibration isolated
  • Air lock doors with air curtain for entry and exit
  • separate pre-cleaning area
  • 15ton centrally air-conditioned plant
  • 25 kva on-line ups to proved clean power
  • highly qualified ,skilled and trained engineers
  • separate store room
  • separate soaking table
  • 15ton centrally air-conditioned plant
  • 25 kva on-line ups to proved clean power
  • highly qualified ,skilled and trained engineers

  • Speciality

  • Nabl accredit ion as per ISO/IEC 17025
  • ISO9001 & AS 9100C Certification
  • imported calibration masters
  • in-house and onsite calibration
  • strictly controlled environmental conditions
  • Temperature      :20 + or -0.5degree C
  • Clean room Class       :III
  • Different air Pressure       : Positive
  • Illumination      : 4500-700Lux
  • Floor area      : 1800 sq.ft.
  • GE Druck U.K Portable pneumatic pressure Gauge Calibrator for Calibration of pressure Gauge upto 700bar,pressure switch,pressure sensor &Transdures ,vaccum gauge etc.. Accureacy : +or -0.025%F.S.
    Range:2.5mbar to 700 bar

    Calipers : Radius gauges Thread &plain ring Gauges
    Micrometers : Feeler gauges   Thread &plain ring Gauges
    Height Gauges : Bore gauges   Thread &plain plug Gauges
    Height Gauges   Spirit levels   Thread &plain taper Gauges
    Dial Gauges   Spirit levels   Measuring pins
    Height masters : slip gauges   Torque wrenches
    Height measuring systems : try squares : pressure Gauges
    Surface plates   Profile projectors : 3D CO-ordinate measuring machine
